• Optional Models

• Optical System

1. Light source: 60pcs 1W LED
2. LED lifespan: min. 50,000 - 80,000 hours
3. Lens angle: 25°
4. 0-100% smooth linear dimming system

• Control and Program

1. LED display
2. Protocol: DMX512, master-slave, sound control, auto
3. Built-in pre-programs
4. Marco function

• Electrical Specification and Connections

1. Power supply: electronic auto-ranging
2. Input voltage: AC90-240 V, 50-60 Hz
3. Power connector in/out: waterproof power plug
4. Data connector in/out: wasterproof 3-pin XLR

• Working Environment

1. Ambient temperature: -20℃ ~ +45℃ (-4℉ ~ +113℉)
2. Protection grade: IP65

• Approvals

1. CE & RoHS
2. If any other certificates are required, confirm with us please

• Product and Packing Dimensions

1. Product: 440*240*120mm (17.3*9.4*4.7inch)
2. Flight case: 530*320*320mm (20.9*12.6*12.6 inch)
3. Net weight: 5.5 kg (12.1 lbs)
4. Gross weight:6.8 kg (15 lbs)
5. Die-castAluminum housing and metal base

• Packing List

1. FLOOD LIGHT 60
2. User manual
3. Waterproof power cable
4. Waterprof 3-pin XLR wire

• Optional Accessories

1. Flight case
2. Clamp
3. Safety rope
4. Extensional DMX wire

、

|
