- Optional Models
| Model No. | IR Control |
| SL-1025 | × |
| SL-1025R | √ |
- Optical System
- Light source: 1PC 12W CREE white LED
- LED lifespan: 50,000 hours
- Beam angle: 13°
- Dynamic Effects
- Colour wheel: 7 color + white
- Fixed gobo wheel: 7 fixed gobo + white
- Gobo shake function
- 5 kinds of dimming mode (standard mode, stage mode, TV mode, building mode, theater mode)
- Linear electronic focusing
- 0-100% lineardimming
- Shutter:18 time/scond high-speed LED electronic strobe
- Control and Program
- Red LED display
- Protocol: DMX512, master-slave, sound control, auto
- Control channels: 9/12 CH
- Pan/Tilt Reverse function
- Movement
- Pan movement: 540°
- Tilt movement: 230°
- Scanning position memory
- Automatic reset
- Electrical Specification and Connections
- Power supply: Electronic auto-ranging
- Input voltage: AC 100-240 V, 50/60 Hz
- Power consumption: 30 W
- Power connector in/out: IEC
- Data connector in/out: 3-pin XLR
- Working Environment
- Ambient temperature: -20℃ ~ +45℃ (-4℉ ~ +113℉)
- Protection grade: IP20
- Approvals
- CE & RoHS
- If any other certificates are required, confirm with us please
- Product and Packing Dimensions
- Product:170*170*280 mm (6.7*6.7*11 inch)
- Carton:300(L)*215(W)*270(H) mm (11.8*8.5*10.6 inch)
- Net weight: 3 kg (6.6 lbs)
- Gross weight: 3.5 kg (7.7 lbs)
- Packing List
- Inno Pocket Spot
- User manual
- Power cable
- 3-pin XLR connectors
- Optional Accessories
- Flight case: 2pcs in 1 (630*410*590 mm=24.8*16.1*23.2 inch, 48 kg=105.8 lbs)
- Clamp
- Safety rope
- DMX wire
