- Optical System
- Light source: 4PCS OSRAM 15W 4in1 LED
- LED lifespan: 50,000 hours
- Zoom range: 10° - 60°
- Dynamic Effects
- RGBW color mixing
- Mixing color Smooth, uniform
- Built macro function
- 0-100% electronic dimmer
- Shutter: 1-25 times/s strobe, plus strobe
- Control and Program
- LED display
- Protocol: DMX512, master-slave, sound control, auto
- Control channels: 10/12/15CH
- Pan/Tilt resolution: 16 bit smooth scanning
- Movement
- Pan movement: 540°
- Tilt movement: 270°
- Scanning position memory
- Automatic Pan/Tilt position correction
- Electrical Specification and Connections
- Power supply: Electronic ballasts and switching
- Input voltage: AC 100-240 V, 50/60 Hz
- Power consumption: 90 W
- Power connector in/out: IEC
- Data connector in/out: 3-pin XLR
- 2 pcs 1/4 fast locking
- Working Environment
- Ambient temperature: -20℃ ~ +45℃ (-4℉ ~ +113℉)
- Protection grade: IP33
- Approvals
- CE & RoHS
- If any other certificates are required, confirm with us please
- Product and Packing Dimensions
- Product: 170*170*260 mm (6.7*6.7*10.2 inch)
- Carton: 300*210*260 mm (11.8*8.3*10.2 inch)
- Net weight: 3 kg (6.6 lbs)
- Gross weight: 3.5 kg (7.7 lbs)
- Packing List
- LEDZOOM 415
- User manual
- Power cable
- 3-pin XLR connectors
- Optional Accessories
- Flight case: 10pcs in 1
- Clamp
- Safety rope
- DMX wire
