. Optional Models
| Model No. | Power | Light Source | Emitting Color | Beam Angle | Optional Beam Angle | DMX Channels |
| SL-3372A 72P3W25D2W | 216 | 72*3W | CW-WW | 45° | 15°/25°/60° | 2/6CH |
| SL-3372A 72P3W25DWW | 216 | 72*3W | 3200K | 45° | 15°/25°/60° | 2CH |
| SL-3372A 72P3W25DCW | 216 | 72*3W | 5600K | 45° | 15°/25°/60° | 2CH |
| SL-3372A 72P3W25DRGBW | 216 | 72*3W | RGBW | 25° | 15°/45°/60° | 4/8CH |
| SL-3372A 108P3W25DRGBW | 324 | 108*3W | RGBW | 25° | 15°/45°/60° | 4/8CH |
. Optical System
- Light source: 72pcs 3W LED
- LED life expectancy: 50,000 - 80,000 hours
- Lens angle: 45°(15°/45°/60°)option
- Dynamic Effects
- 0-100% smooth linear dimming system
- Shutter: 1-18 times/sec high speed strobe, speed adjustable
- With random strobe and pulse effect
- Control and Program
- DMX512, master-slave, sound control, auto programs
- Built-in pre-program
- Marco function
- Electrical Specification and Connections
- Input voltage: AC 90-240 V, 50-60 Hz, auto ranging
- Data connector in/out: 3-pin XLR
- Working Environment
- Ambient temperature: -25℃ ~ +45℃ (-13℉ ~ +113℉)
- Protection grade: IP20
- Approvals
- CE, RoHS,
- If any other certificates are required, confirm with us please
- Product and Packing Dimensions
- Product: 480*315*355 mm (18.9*12.4*14.0inch)
- Box: 490*400*230 mm (19.3*15.7*9.1inch)
- Net weight: 8.2kg (18.1 lbs)
- Gross weight: 9.2 kg (20.3 lbs)
- Packing List
- Led studio light 723
- User manual
- Power cable
- Optional Accessories
- Flight case:4pcs-in-1
- Clamp
- Safety rope
- DMX wire
