- Optional Models
| Model No. | Power Consumption | Light Source | Emitting Color | Lens Angle | Lens Optional | DMX Channels |
| SL-2480-4IN1 48P25D | 480W | 48*10W | 4in1 | 25° | 15°, 45°, 60° | 4/8 CH |
| SL-2480A 96P3W25DRGBW | 288W | 96*3W | RGBW | 25° | 15°, 45°, 60° | 4/8 CH |
| SL-2480A 108P3W25DRGB | 288W | 108*3W | RGB | 25° | 45° | 3/7 CH |
- Optical System
- Light source: 48/96/108pcs high brightness LED
- LED lifespan: min. 50,000 - 80,000 hours
- Lens angle: 25°
- Dynamic Effects
- LED rainbow effect
- 0-100% smooth linear dimming system
- Shutter: 1-18 times/sec high speed strobe, speed adjustable
- With random strobe and pulse effect
- Control and Program
- LED display
- Protocol: DMX512, master-slave, sound control, auto
- Built-in pre-programs
- Marco function
- Electrical Specification and Connections
- Power supply: electronic auto-ranging
- Input voltage: AC 90-240 V, 50-60 Hz
- Power connector in/out: waterproof power plug
- Data connector in/out: wasterproof 3-pin XLR
- Working Environment
- Ambient temperature: -20℃ ~ +45℃ (-4℉ ~ +113℉)
- Protection grade: IP65
- Approvals
- CE & RoHS
- If any other certificates are required, confirm with us please
- Product and Packing Dimensions
- Product: 560*160*320 mm (22*6.3*12.6 inch)
- Carton: 680*210*370 mm (26.8*8.3*14.6 inch)
- Net weight: 17.3 kg (38.1 lbs)
- Gross weight: 18.5 kg (40.8 lbs)
- Die-cast aluminum housing and metal base
- Packing List
- LEDARC 480
- User manual
- Waterproof power cable
- Waterprof 3-pin XLR wire
- Optional Accessories
- Flight case
- Clamp
- Safety rope
- Extensional DMX wire
