- Optional Models
| Model No. | Power | Light | Emitting | DMX |
| Consumption | Source | Color | Channels | |
| SL-1006A-4IN1 | 360W | 36*10W | 4in1 | 10/15 CH |
| SL-1006A-5IN1 | 540W | 36*15W | 5in1 | 14/17 CH |
| SL-1006A-6IN1 | 648W | 36*18W | 6in1 | 14/19 CH |
- Optical System
- Light source: 36pcs high brightness LED
- LED lifespan: min. 50,000 - 80,000 hours
- Lens angle: 25° / 45°
- Dynamic Effects
- LED rainbow effect
- 0-100% smooth linear dimming system
- Shutter: 1-18 times/sec high speed strobe, speed adjustable
- With random strobe and pulse effect
- Control and Program
- Color touch screen
- LCD display, brightness and contrast ratio adjustable
- Protocol: DMX512, master-slave, sound control, auto
- Built-in 8 pre-programs
- Marco function
- Movement
- Pan movement: 630°
- Tilt movement: 270°
- Scanning position memory
- Automatic Pan/Tilt position correction
- Pan/Tilt resolution: 16 bit smooth scanning
- Electrical Specification and Connections
- Power supply: electronic auto-ranging
- Input voltage: AC 100-240 V, 50-60 Hz
- Power connector in/out: IEC standard
- Data connector in/out: 3-pin XLR
- Working Environment
- Ambient temperature: -20℃ ~ +45℃ (-4℉ ~ +113℉)
- Protection grade: IP33
- Approvals
- CE & RoHS
- If any other certificates are required, confirm with us please
- Product and Packing Dimensions
- Product: 340*230*470 mm (13.4*9.1*18.5 inch)
- Carton: 430*300*390 mm (16.9*11.8*15.4 inch)
- Net weight: 9.5 kg (20.9 lbs)
- Gross weight: 11 kg (24.3 lbs)
- Packing List
- LEDWASH 360
- User manual
- Power cable
- 3-pin XLR connectors
- Optional Accessories
- Flight case: 2pcs-in-1, 4pcs-in-1
- Clamp
- Safety rope
- DMX wire
