- Optional Models
| Model No. | Power | Light Source | Emitting Color | Beam Angle | DMX Channels |
| SL-3125B | 150 | 5*30W | 3IN1 | 8/15/20CH | |
| SL-3125B 6500K | 50 | 5*10W | 6500K | 5° | 5/9CH |
- Optical System
- Light source: 5X30W 3IN1 LED
- LED life expectancy: 50,000 - 80,000 hours
- Lens angle: 25°
- Dynamic Effects
- 5 pixels (each LED is a pixel), controllable individually
- 0-100% smooth linear dimming system
- Shutter: 1-20 times/sec high speed strobe, speed adjustable
- Control and Program
- DMX512, master-slave, sound control, auto programs
- Control Channels: 8/15/20 DMX channels
- Built-in pre-program
- Marco function
- Electrical Specification and Connections
- Input voltage: AC 90-240 V, 50-60 Hz, auto ranging
- Power connector in/out: IEC standard
- Data connector in/out: 3-pin XLR
- Working Environment
- Ambient temperature: -25℃ ~ +45℃ (-13℉ ~ +113℉)
- Protection grade: IP20
- Approvals
- CE, RoHS,
- If any other certificates are required, confirm with us please
- Product and Packing Dimensions
- Product: 610*150*240 mm (24.0*5.9*9.4inch)
- Box: 650*190*270 mm (25.6*7.5*10.6inch)
- Net weight: 4.0 kg (8.8 lbs)
- Gross weight: 5.2 kg (11.5 lbs)
- Carton (4pcs-in-1): 695*400*445mm, 22kg (27.4*15.7*17.5 inch, 48.5 lbs)
- Packing List
- Led matrix 530
- User manual
- Power cable
- Optional Accessories
- Flight case: 8pcs-in-1
- Clamp
- Safety rope
- DMX wire
