- Optical System
- Light source: 8PCS 10W 4in1 LED(RGBW)
- LED lifespan: 50,000 hours
- Beam angle: 6°
- Dynamic Effects
- Pixel control: 8 pixel (each LED as a pixel), individually controllable
- Amazing streaming effect
- Built-in default program and easy to operate
- 12 default pixel macro effect
- 0-100% electronic dimmer
- Shutter: 1-18 times/s strobe, plus strobe
- Control and Program
- LED display
- Protocol: DMX512, master-slave, sound control, auto
- Control channels: 10/38 CH
- Pan/Tilt resolution: 16 bit smooth scanning
- Movement
- Pan movement: 540°
- Tilt movement: 270°
- Scanning position memory
- Automatic Pan/Tilt position correction
- Electrical Specification and Connections
- Power supply: Electronic ballasts and switching
- Input voltage: AC 100-240 V, 50/60 Hz
- Power consumption: 120 W
- Power connector in/out: Powercon
- Data connector in/out: 3-pin XLR
- 2pcs 1/4 fast locking
- Housing
- Head: Aluminum cooling system, no noise
- Bottom: Low-noise fan cooling system
- Working Environment
- Ambient temperature: -20℃ ~ +45℃ (-4℉ ~ +113℉)
- Protection grade: IP20
- Approvals
- CE & RoHS
- If any other certificates are required, confirm with us please
- Product and Packing Dimensions
- Product: 1065*80*160 mm (41.9*3.1*6.3 inch)
- Carton: 1140*170*220 mm (44.9*6.7*8.7 inch)
- Net weight: 6.5 kg (14.3 lbs)
- Gross weight: 7.2 kg (15.9 lbs)
- Packing List
- BEAM 8 4IN1
- User manual
- Power cable
- 3-pin XLR connectors
- Optional Accessories
- Flight case
- Clamp
- Safety rope
- DMX wire
